Honeywell ScanPal EDA10A
A rugged yet lightweight solution for mobile business users who need fast, reliable mobile data access on a 10" screen.
Aimed at business users, the EDA10A comes with a full-service offering, compatibility with a rich assortment of enterprise software, and an extensive line of accessories including desktop and vehicle charge docks, a display dock that enables the creation of a workstation with a keyboard and mouse, and a large, hot-swappable battery.
- Rugged and sleek design to endure frequent drops and vibrations
- Removable 8,000mAh lithium-ion battery
- Scan barcodes, even damaged ones, with the Honeywell enterprise-level S0703 imager
- Gorilla Glass 5 and multi-touch screen that supports glove / wet hand / oily hand modes
Got a project or need bulk pricing? Get in touch.
Product Specifications
| Mobile Computing Platform | Qualcomm Snapdragon SM4350-AC, Octa-Core, up to 2.2GHz |
| Operating System | Android 12 |
| RAM | 4GB / 8GB |
| Storage | 64GB Flash / 128GB Flash |
| LCD | 10.1" Full HD, Gorilla Glass 5 |
| Resolution | 1920 x 1200 |
| Dimensions (WxHxD) | 257 x 166.5 x 11.7 mm |
| Weight | 674g |
| Bluetooth™ | Class 5.1/2.1 + EDR Class 2 (Bluetooth LE) |
| Wireless LAN | IEEE 802.11 a/b/g/n/ac/ax |
| Front Camera | 8 megapixel colour camera |
| Rear Camera | 16 megapixel colour camera |
| Touch Panel | Multi-touch capacitive (CTP), GFF |
| Sensors | 3-axes accelerometer, 3-axes gyroscope sensor, compass, light sensor, and proximity sensor |
| Hard Keys | 5 side keys for volume up/down, right/left scanning and power on/off, 1 touch key on bottom side for scanning |
| Battery | Li-Ion, 8,000 mAh, 3.85 V, removable, hot swappable |
| Temperature | Operating: -20°C to 50°C Storage: -30°C to 70°C |
| Humidity | 5% to 95% (non-condensing) |
Product Certifications
| Drop | Multiple 1.3 m (4.3 ft) drop to concrete per MIL-STD-810H under room temperature. With optional protective boot, multiple 2.0 m (6.6 ft) drop to concrete per MIL-STD-810H under room temperature |
| Environmental | IP65 |
| Electrostatic Discharge (ESD) | ±8kV direct; ±15kV air |
| Vibration | MIL-STD-810H, Method 514.6, Procedure I |
Warranty
| Factory Warranty | One-year |
